SATEX Topper

✅ High-quality frame system, made of highly qualified steel.

✅ Then only machine on the market where all three parts follow the ground separately.

✅ Ground, sharpened steel blades.

✅ High efficiency at a working speed of 13-15 km/h.

Cambridge

✅ High-quality frame system, made of highly qualified steel.

✅ Then only machine on the market where all three parts follow the ground separately.

✅ Cast iron work bodies.

✅ Depending on the rotor type, with a shaft up to 70 mm in diameter.

Topper – high-performance residue cutter

The Satex Topper is a powerful residue cutter, primarily designed for chopping sunflower stalks, but equally effective on other crop residues. It is equipped with highly alloyed steel blades, providing excellent wear resistance and consistent cutting performance even under demanding conditions.

One of Topper’s key advantages is its refined and unique ground-following system. The machine accurately adapts to surface contours, ensuring uniform residue processing across the full working width. It can be operated either pulled behind the tractor or pushed via the front hydraulic linkage, offering exceptional operational flexibility.

Topper can be efficiently combined with other implements, such as mounting the Topper on the front and a short disc harrow or cultivator on the rear. This setup reduces the number of passes, saves fuel, and significantly increases field efficiency.

In reduced tillage systems, crop residues play a vital role. Properly managed residues protect the soil from erosion, help retain moisture, enhance biological activity, and contribute to increased organic matter content. The Topper plays a key role in this process by finely chopping plant material and creating optimal conditions for subsequent operations and crop establishment.

Cambridge – cast iron roller for effective soil consolidation

The Satex Cambridge roller is built from robust cast iron rings and mounted on the same heavy-duty frame as the Topper. As a result, it offers equally precise ground following and uniform soil consolidation.

The Cambridge roller is used to break clods, close the soil surface, and compact the seedbed. Its application improves seed-to-soil contact, promotes even crop emergence, and reduces moisture loss. It is especially beneficial before or after sowing, as well as following shallow tillage.

⚠️ Important operating guidelines

For both Topper and Cambridge, we strongly advise against turning in tight radii or turning with the machine engaged at all. Such maneuvers place excessive stress on the frame and working components, which can negatively affect long-term durability.

Modular system – one frame, two functions

One of the main advantages of the Satex system is its modular design. Since both implements are mounted on the same frame, customers can purchase the Topper and simply add Cambridge roller segments. Depending on requirements, the implement can be converted from Topper to Cambridge by removing just a few bolts – making it a fast, simple, and cost-effective solution.

Technical Characteristics - Cambridge & Topper

No. Name Power (HP) Working width Knives / Springs Transport width Weight (kg)
01. Clot-Crasher 2,0 m mounted 35-50 HP 2 m -/- 2 m 750 kg
02. Clot-Crasher 3,0 m mounted – single-section 45-60 HP 3 m -/- 3 m 1000 kg
03. Clot-Crasher 3,0 m mounted – folding 45-60 HP 3 m -/- 2,6 m 1100 kg
04. Clot-Crasher 3,0 m trailed 45-60 HP 3 m -/- 2,6 m 1200 kg
05. Clot-Crasher 4,0 m mounted 60-80 HP 4 m -/- 2,6 m 2000 kg
06. Clot-Crasher 4,5 m mounted 80-90 HP 4,5 m -/- 2,6 m 2200 kg
07. Clot-Crasher 4,5 m trailed 60-80 HP 4,5 m -/- 2,4 m 2400 kg
08. Clot-Crasher 5,1 m trailed 70-90 HP 5,1 m -/- 2,5 m 3000 kg
09. Clot-Crasher 6,0 m trailed 80-110 HP 6 m -/- 2,5 m 3300 kg
10. Clot-Crasher 8,0 m trailed 150-170 HP 8 m -/- 3 m 5800 kg
11. Clot-Crasher with leveler 4,5 m 100 HP 4,5 m Crosboard - 18 2,5 m 3000 kg
12. Clot-Crasher with leveler 5,1 m 120 HP 5,1 m Crosboard - 20 2,5 m 3350 kg
13. Clot-Crasher with leveler 6,0 m 140 HP 6 m Crosboard - 22 2,5 m 3600 kg
14. Clot-Crasher with leveler 8,0 m 170-200 HP 8 m Crosboard - 32 3 m 6400 kg
15. TOPPER 3,0 m mounted 50 HP 3 m - 3 m 600 kg
16. TOPPER 4,5 m mounted 80 HP 4,5 m - 2,5 m 1430 kg
17. TOPPER 4,5 m trailed 90 HP 4,5 m - 2,5 m 1680 kg
18. TOPPER 5,1 m trailed 105 HP 5,1 m - 2,5 m 1740 kg
19. TOPPER 6,0 m trailed 120 HP 6 m - 2,5 m 1800 kg
20. TOPPER 8,0 m trailed 130 HP 8 m - 3 m 4500 kg
21. Cambridge topper 4,5 m 90 HP 4,5 m - 2,5 m 3000 kg
22. Cambridge topper 6,0 m 120 HP 6 m - 2,5 m 3600 kg
